SPECIFICATIONS
Delay Function 0.02 to 200 msec (4 decades); Separates PREPULSE SYNC OUT pulse from the stimulus pulse; Used to set refractory time interval for TWIN PULSE operation
Synchronous Outputs PREPULSE SYNC OUT precedes the stimulus pulse as selected by the variable delay; PULSE SYNC OUT occurs at the end of delay period which is coincident with the onset of the stimulus pulse
Frequency 0.2 to 200 PPS (3 decades)
Duration 0.02 to 200 msec (4 decades)
Output Volts (Peak) 0.1 to 100 volts (3 decades)
Output Impedance ²1 kohm
Maximum Power Out 2.5 watts peak
Sync Input and Output +5 volts, TTL compatible
Output Isolation Circuit Built-in to allow recording with the stimulator at the preparation site with minimum artifact; Output voltage not referred to ground; Output polarity selectable
Biphasic Output Can be selected to reduce electrode polarization and ion transfer
Monitor Lamps
Flashes with each stimulus pulse
Accuracy ±10% or better for all parameters
Maximum Power 30 watts at 110 volts, 50/60 Hz; Typical Power is 5 watts
Physical Size 9.5" W x 5.25" H x 5.5" D (24.1 cm x 13.3 cm x 14 cm)
Weight 3.7 lbs. (1.6 kg)
Regulatory Safety: UL 3101-1, CSA C22.2 No. 1010-1, EN 61010-1 Other European Standards: EN 55011, EN 50082-1 European Directives: 73/23/EEC, 89/336/EEC
